ArashiTurbo 3″ Cover TD05H-BIG16G-12cm2 Anti-surge Mitsubishi Lancer EVO X 4B11TBillet Wheel Turbocharger

With very little effort, this Arashi turbocharger installs on your EVO X perfectly with dramatic increase of up to 300-600HP while the stock turbo runs about 250HP. To enhance its durability, turbine housing is specially made with 22% Nickel. Full installation kit is included for easy installation and there are 18 setup options for the boost range with the adjustable actuator.

Brand New and Complete CHRAs balanced by VSR Core-Balancing Machine from Turbo Technics.

Application

Mitsubishi Lancer 4B11T EVO X / EVO 10

Arashi Item No.

Replacement For.

– Stock TD05H Turbo P/N 49378-01641, 49378-01642, etc

– RequireExtra 3.15 inches Pipe

Turbine Wheel

TD05H

Turbine Diameter

49.2/55.8mm (9 Blades) We also offer 12 blades. Please let us know if you need to change.

Turbine Housing

12cm^2 / 0.89 A/R with Ni 22% turbine housing which endures higher temperature

CompressorHousing

3.15″ inlet / 80 mm / Anti-surge

Compressor Wheel

BIG16G (Billet)

Compressor Diameter

48.3/68 mm (GTX 11 Blades) We also offer 6+6 Blades. Please let us know if you need to change.

Compressor CFM

–

Cooling

Water & Oil Cooled

Bearing

Arashi Racing 360 degrees UPGRADE Journal Bearing

Package Included

Gaskets , extra springs and Install Kit

Flange

Standard EVO X

Actuator

1.1 bar spring pre-installed on adjustable actuator.(18 ways for application)
