Garrett GEN2 GTX3582R dual ball bearing turbocharger. Advanced GEN2 billet compressor wheel capable of 850HP!

• .82 A/R
• Open (Undivided) T3 Turbine Housing (ATP-HSG-002)
• 3″ GT 4 Bolt conical exit

The Garrett GEN2 GTX3582R fits turbine housings for Garrett GT35 and GTX35 series turbochargers with a 68mm inducer and 84 trim turbine wheel.

Product Features:

• Advanced aerodynamics & ultra high flow Garrett GTX GEN2 compressor wheel
• Forged billet aluminum compressor wheel
• Dual ball bearing CHRA rotating assembly

Product Specifications:

• Compressor Wheel Inducer: 66mm
• Compressor Wheel Exducer: 82mm
• Compressor Wheel Trim: 64
• Compressor Housing A/R: 0.70, T04S Frame: 4″ in / 2.5″ out
• Turbine Wheel Inducer: 68mm
• Turbine Wheel Exducer: 62mm
• Turbine Wheel Trim: 84

Turbine Housing Options:

• Ni-Resist V-Band Inlet & Outlet. Available in .61, .83 or 1.01 A/R

Alternative Turbine Housing Options:

• T4 Inlet and 3.0″ GT V-Band Outlet. Available in .63, .82, or 1.06 A/RProduct Code: ATP-HSG-046
• T4 Divided Inlet and 3.0″ V-Band Outlet. Available in 1.06 A/RProduct Code: ATP-HSG-063
• T3 Inlet, Internally Gated, and 5 bolt Outlet. Available in .63, .82, or 1.06 A/RProduct Code: ATP-HSG-037
• T3 Divided Inlet and 3.0″ V-Band Outlet. Available in.82 A/R,1.06 A/R
• TiAL Stainless Steel V-Band Inlet & Outlet. Available in.63 A/R,.82 A/R,1.03 A/R

Additional turbine housing options available in the

Turbine Housing Section. Available here!Coolant (Water) & Oil Fittings, Flanges, and Components Solutions:

• Coolant – Water Options (Requires 2 units):14mm Coolant Fitting & Lines
• Oil feed options:-4 AN with built-in Restrictor (Product Code: ATP-OIL-021)
• Oil drain flange:Product Code: ATP-FLA-010
• Oil drain gasket:Product Code: GRT-GSK-008
• 8mm x 1.25 (thread pitch) Stud:Product Code: MIA-FST-030
• 8mm x 1.25 (thread pitch) Locking Head Nut:Product Code: MIA-FST-031

• T3 Inlet Weld Flange (Stainless Steel): Product Code:ATP-FLS-038(ATP-FLS-001-mild steel)
• Gasket, T3 Turbine Inlet – UNDIVIDED: Product Code:GRT-GSK-005
• Discharge Flange GT 4 Bolt 3″ (Stainless Steel): Product Code:ATP-FLS-085(ATP-FLS-013-mild steel)
• Gasket, Downpipe (Turbine outlet) Gasket, “GT 4 Bolt 3” opening: Product Code:ATP-GSK-018
